Chapter 9 Operating Instructions
Flexi Classic Gateways
108 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
EtherNet/IP Gateway
Instance 2 - data set 2 attribute definitions
Attribute number Data set parameter Size
2 MQD1 SINT
3 MQD2 SINT
4 MQD3 SINT
5 MQD4 SINT
6 MQD5 SINT
7 MQD6 SINT
8 MQD7 SINT
9 MQD8 SINT
10 MQD9 SINT
11 MQD10 SINT
12 MQD11 SINT
13 MQD12 SINT
14 MQD13 SINT
Instance 3 - data set 3 attribute definitions
Attribute number Data set parameter Size
2 DIG_OUT
Bit 0 (0x01) = Digital Output 1
Bit 1 (0x02) = Digital Output 2
Bit 2 (0x04) = Digital Output 4
Bit 3 (0x08) = Digital Output 8
UINT
Instance 4 - data set 4 attribute definitions
Attribute number Data set parameter Size
2 BAS1 SINT
3 Backplane Fault SINT
4 CRC (System) UINT
Instance 5 - data set 5 attribute definitions
Attribute number Data set parameter Size
2 MFD1 SINT
3 MFD2 SINT
4 MFD3 SINT
5 MFD4 SINT
6 MFD5 SINT
7 MFD6 SINT
8 MFD7 SINT
Tab.
100
:
Individual Data Set
Transfer Object (73hex)
instance 2 attribute
definitions
Tab.
101
:
Individual Data Set
Transfer Object (73hex)
instance 3 attribute
definitions
Tab.
102
:
Individual Data Set
Transfer Object (73hex)
instance 4 attribute
definitions
Tab.
103
:
Individual Data Set
Transfer Object (73hex)
instance 5 attribute
definitions
