SICK Flexi Classic User Manual

Chapter 3 Operating Instructions
Flexi Classic Gateways
16 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
Flexi Classic gateways
3.2.9 B1-B10 (REQ-ID 1-13/2133)
The following assignment of configuration data to B1-B10 applies for the REQ-IDs 21-33:
REQ-ID 1-13 REQ-ID 21-33
B1 MED MOD-ID
B2 MQD SW-VERSION_H
B3 MKD1 SW-VERSION_L
B4 MKD2 FUNCTION
B5 MFD KONF
B6 MFCLASS1 CRC_H CODE
B7 MFCODE1 CRC_L CODE
B8 MFCLASS2 –
B9 MFCODE2 –
B10 RSP-ID RSP-ID
3.2.10 B1-B10 (REQ-ID 255)
Control byte for PROFIBUS communication
For the REQ-ID 255 the following assignment of configuration data to B1-B10 applies:
B1 DIAG-VERSION_H
B2 DIAG-VERSION_L
B3 BUS ADDR Contains the fieldbus address currently set
(dynamic)
B4 NOISE
B5 FRAME
B6 BREAK
B7 PARITY
4 bytes that contain the number of transmission
errors that have occurred on a bus system
B8 –
B9 –
B10 RSP-ID
3.2.11 MED
Module input data (input states)
Bit 7 6 5 4 3 2 1 Bit 0
UE410-MU
UE410-XU
S3 S2 S1 EN I4 I3 I2 I1
UE410-GU I4 I3 I2 I1 I
N
I6 I5 I
P
UE410-8DI I8 I7 I6 I5 I4 I3 I2 I1
UE410-MM
UE410-XM
I2 I1 S1 EN M4 M3 M2 M1
UE410-MDI 0 0 0 0 S4 OVR CS C1
Input states 0 = Input is inactive
1 = Input is active
Tab.
10
:
B1
-
B10
(REQ0ID 21033)
Tab.
11
:
B1
-
B10
(REQ0ID 255)
Tab.
12
:
MED
