SICK Flexi Classic User Manual

Chapter 9 Operating Instructions
Flexi Classic Gateways
120 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
EtherNet/IP Gateway
9.10.2 Data set 6, can be compiled by the user
The contents of Data set 6 can be compiled by the user.
If the option Return only enabled Data is activated in the configuration of the data set
(see section “Configuration …” above), the data set can have a different length depending
on the compilation. The maximum length is 124 bytes. The minimum length is 2 bytes.
The selected data are transferred for all Flexi Classic modules respectively.
The data are zeroed for modules that do not exist.
If data is expected in 16-bit words and in the format Big Endian (e.g. Modbus/TCP), it is
transferred with the more significant byte first.
Data set 6
Byte
1-124
CRC-H CRC-L
MKD1.1 MKD2.1 MKD1.2 MKD2.2 MKD1.3 MKD2.3
MKD1.4 MKD2.4 MKD1.5 MKD2.5 MKD1.6 MKD2.6
MKD1.7 MKD2.7 MKD1.8 MKD2.8 MKD1.9 MKD2.9
MKD1.10 MKD2.10 MKD1.11 MKD2.11 MKD1.12 MKD2.12
MKD1.13 MKD2.13
MOD-ID1 MOD-ID2 MOD-ID3 MOD-ID4 MOD-ID5 MOD-ID6
MOD-ID7 MOD-ID8 MOD-ID9 MOD-ID10 MOD-ID11 MOD-D12
MOD-13 0
SW Version
Byte 1,
Module 1
SW Version
Byte 2,
Module 1
SW Version
Byte 1,
Module 2
SW Version
Byte 2,
Module 2
SW Version
Byte 1,
Module 3
SW Version
Byte 2,
Module 3
SW Version
Byte 1,
Module 4
SW Version
Byte 2,
Module 4
SW Version
Byte 1,
Module 5
SW Version
Byte 2,
Module 5
SW Version
Byte 1,
Module 6
SW Version
Byte 2,
Module 6
SW Version
Byte 1,
Module 7
SW Version
Byte 2,
Module 7
SW Version
Byte 1,
Module 8
SW Version
Byte 2,
Module 8
SW Version
Byte 1,
Module 9
SW Version
Byte 2,
Module 9
SW Version
Byte 1,
Module 10
SW Version
Byte 2,
Module 10
SW Version
Byte 1,
Module 11
SW Version
Byte 2,
Module 11
SW Version
Byte 1,
Module 12
SW Version
Byte 2,
Module 12
SW Version
Byte 1,
Module 13
SW Version
Byte 2,
Module 13
Function 1 Function 2 Function 3 Function 4 Function 5 Function 6
Function 7 Function 8 Function 9 Function 10 Function 11 Function 12
Function 13 0
Note
Tab.
112
:
Data set 6 of the
UE410-EN
