SICK Flexi Classic User Manual

Chapter 9 Operating Instructions
Flexi Classic Gateways
118 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
EtherNet/IP Gateway
9.10 Description of the data sets
9.10.1 Data sets 1-5
The compilation of data sets 1-5 is fixed; these data sets can only be activated or deactiva-
ted as a whole. The length of these data sets is always the same. The data will be zeroed
for modules that do not exist.
Data set 1 Data set 2 Data set 3 Data set 4 Data set 5
Input data Output data Gateway-
specific
diagnostic
data
General
diagnostic
data
Module-specific
diagnostic data
Byte 1 MED1 MQD1 DIG_OUT1 BAS1 MFD1
Byte 2 MED2 MQD2 DIG_OUT2 Backplane
Fault
MFD2
Byte 3 MED3 MQD3 – CRC1 MFD3
Byte 4 MED4 MQD4 – CRC2 MFD4
Byte 5 MED5 MQD5 – – MFD5
Byte 6 MED6 MQD6 – – MFD6
Byte 7 MED7 MQD7 – – MFD7
Byte 8 MED8 MQD8 – – MFD8
Byte 9 MED9 MQD9 – – MFD9
Byte 10 MED10 MQD10 – – MFD10
Byte 11 MED11 MQD11 – – MFD11
Byte 12 MED12 MQD12 – – MFD12
Byte 13 MED13 MQD13 – – MFD13
Byte 14 0* 0* – – 0*
Byte 15-18 – – – – MFCLASS1/ CODE1,
MFCLASS2/CODE2 (1)
Byte 19-22 – – – – MFCLASS1/ CODE1,
MFCLASS2/CODE2 (2)
Byte 23-26 – – – – MFCLASS1/ CODE1,
MFCLASS2/CODE2 (3)
Byte 27-30 – – – – MFCLASS1/ CODE1,
MFCLASS2/CODE2 (4)
Byte 31-34 – – – – MFCLASS1/ CODE1,
MFCLASS2/CODE2 (5)
Byte 35-38 – – – – MFCLASS1/ CODE1,
MFCLASS2/CODE2 (6)
Byte 39-42 – – – – MFCLASS1/ CODE1,
MFCLASS2/CODE2 (7)
Byte 43-46 – – – – MFCLASS1/ CODE1,
MFCLASS2/CODE2 (8)
Tab.
111
:
Data sets 1
–
5 of
the UE410-EN
