Technical specifications
11.1.3 DeviceNet
Interface Min. Typ. Max.
Fieldbus DeviceNet (Group 2 Only Server)
Interface level ISO DIS 11898
Connector technology
Open style connector,
5-pin removable terminal
Slave address 0 63
Baud rate 125 kBit/s 250 kBit/s 500 kBit/s
Function Gateway
Function indication 3 LEDs green/red
Controls
2 switches 10-position
1 DIP switch, 4-pole
Terminals
Removable screw terminals
Max. number of modules /
status in the system
1 / interaction-free slave on the internal safety bus, slave on the
fieldbus
Cable parameters see chapter 6 “DeviceNet Gateway” from p. 47.
11.1.4 Modbus/TCP, EtherNet/IP, PROFINET IO
Interface Min. Typ. Max.
Fieldbus Modbus/TCP, EtherNet/IP, PROFINET IO
Integrated switch 3-Port layer-2 managed switch with Auto-MDI-X for automatic detection
of crossed Ethernet cable
Connection technique RJ45 socket
Transfer rate 10 Mbit/sec (10Base-T) or 100 Mbit/sec (100Base-T), autosensing
Cable length Max. 100 m per segment
Addressing factory
setting
IP: 192.168.250.250
Subnet mask: 255.255.0.0
Default gateway: 0.0.0.0
