Chapter 9 Operating Instructions
Flexi Classic Gateways
98 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
EtherNet/IP Gateway
Selection/entry
window
Factory
setting
Description
Write All Enabled
Data Sets to Data
Set 1 Tag/File
Deactivated Specifies whether to write all enabled data sets to the Data Set
1 Tag/File address. If selected, the first 16 bit word will contain
an incrementing sequence number and all enabled data sets
will follow in order.
Rx Data Set
Tag/File Names
1 Specifies the tag or file names on the PLC where the data sets
are to be sent to.
For ControlLogix PLCs, the tag names must be controller wide
and must be an array of type INT (16 bit word) large enough to
hold the entire data set message.
For SLC/PLC-5 PLCs, the file names must begin with a “$”
(i.e. $N10:0).
For MicroLogix PLCs, the file names must begin with a “#”
(i.e. #N10:0).
Settings for the operating mode Read-from-Tag/file:
Digital Output
Polling Enable
Deactivated
Specifies whether the UE410-EN1 is to request the value of the
digital outputs from the PLC.
Digital Output
Tag/File Name
Specifies the PLC tag or file name where the UE410-EN will
request the Digital output values.
For ControlLogix PLCs, the tag names must be controller wide
and be of either SINT, INT, DINT, or BOOL[32] bit array.
For SLC, PLC-5, or MicroLogix PLCs, the file data type must be
either Integer (N) or Binary (B).
The same file naming rules apply as for the Tag/File names.
Digital Output
Setting Polling
Rate
200 Specifies the interval in milliseconds in which the value of the
digital outputs is requested.
Minimum = 10 ms., Maximum = 65535 ms.
All data sets are transferred to the PLC in 16 bit integer format with the first byte placed in
the most significant, or leftmost byte of the integer.
9.4.1 Operating modes in the transfer mode Rx (to PLC)
Polling — PLC requests the data from UE410-EN
In this operating mode the UE410-EN sends the data as slave upon request from the PLC.
If this operating mode is desired:
 Chose the operating mode Polling in the Rx (To PLC) Ethernet Transfer Method
selection field. All further settings do not apply.
 Activate Save in Flash and click Submit to save the selection.
Only if Save in Flash is checked will the new configuration be stored in the UE410-EN’s
non-volatile memory and be available after a restart of the gateway. Submit without
checking Save in Flash allows, for example, the testing of new configurations without
overwriting the old configuration.
