SICK Flexi Classic User Manual

Operating Instructions Chapter 3
Flexi Classic Gateways
8011834/YT28/2016-03-15 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
15
Subject to change without notice
Flexi Classic gateways
3.2.6 BAS3
Output data from the A/B function groups on the UE410-XU main module, the UE410-8DI
expansion modules and the UE410-XM, UE410-MDI muting modules.
Bit 7 6 5 4 3 2 1 Bit 0
MOD6 MOD7 MOD8 MOD9
3.2.7 BAS4
Output data from the A/B function groups on the UE410-XU main module, the UE410-8DI
expansion modules and the UE410-XM, UE410-MDI muting modules.
Bit 7 6 5 4 3 2 1 Bit 0
MOD10 MOD11 MOD12 MOD13
For BAS2, BAS3, BAS4 the following definitions apply:
UE410-XU
00 = Q1/Q2 inactive and Q4 inactive
01 = Q1/Q2 inactive and Q4 active
10 = Q1/Q2 active and Q4 inactive
11 = Q1/Q2 active and Q4 active
MODn
X = Unused
UE410-8DI
00 = Q
A
inactive and Q
B
inactive
01 = Q
A
inactive and Q
B
active
10 = Q
A
active and Q
B
inactive
11 = Q
A
active and Q
B
active
MODn
Q
A
/ Q
B
are set if:
• all inputs on the function group (A or B) are in the valid ON state
• the OR function is valid
• the bypass function is valid
UE410-XM
00 = Q
1/2
and Q
3/4
inactive MODn
10 = Q
1/2
active
UE410-MDI
MODn 00 = Always 0, as module has no outputs
3.2.8 RSP-ID
Status byte for the assignment of the 10 bytes B1-B10.
The RSP-ID is used to confirm that the required contents have been provided by the gate-
way in B1-B10. When the RSP-ID has the same value as the REQ-ID, the data transfer is
complete.
As PLC cycles, fieldbus cycles and diagnostics cycles are generally not synchronised, on a
change in the REQ-ID the PLC should always wait for the RSP-ID prior to the evaluation of
the bytes B1-B10.
Tab.
7
:
BAS3
Tab.
8
:
BAS4
Note
Tab.
9
:
Definitions for BAS2,
BAS3, BAS4
Note
