Flexi Classic gateways
ErrCode for ErrClass 0Ah:
For base module
M 01 Logical error in input group A
M 10 Logical error in input group B
M 11 Logical error in input groups A and B
M 02 Logical error in the start function group A
M 20 Logical error in the start function group B
M 22 Logical error in the start function groups A and B
M 08 Logical error in the bypass function group A
M 80 Logical error in the bypass function group B
M 88 Logical error in the bypass function groups A and B
For muting master/slave:
M 01 Logical error in input group A
M 10 Logical error in input group B
M 11 Logical error in input groups A and B
M 02 Logical error in the start function group A
M 20 Logical error in the start function group B
M 22 Logical error in the start function groups A and B
M 04 Logical error in the output function group A
M 40 Logical error in the output function group B
M 44 Logical error in the output function groups A and B
M 08 Logical error in the bypass function group A
M 80 Logical error in the bypass function group B
M 88 Logical error in the bypass function groups A and B
(M = Bit mask; several errors can occur at the same time)
On the occurrence of error codes other than those listed here, please contact the SICK
technical hotline.
3.2.17 MOD-ID
Module identifier for the selected Flexi Classic module (not UE410-GU).
Bit 7 6 5 4 3 2 1 Bit 0
MOD-ID
MOD-ID Module identifier 1 = UE410-MU
2 = UE410-XU
3 = UE410-8DI
4 = UE410-MM
5 = UE410-XM
6 = UE410-MDI
Note
Tab.
21
:
MOD
-
ID
