Operating Instructions Chapter 3
Flexi Classic Gateways
8011834/YT28/2016-03-15 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
23
Subject to change without notice
Flexi Classic gateways
ErrCode for ErrClass 09h:
01 Modules incompatible
02 Configuration change detected
09 SDO client invalid state
0A Unknown SDO-cnf
0B Unused SDO index
0C SDO7 in slot list missing for at least 1 module
0D Index error in slot list
0E Invalid position switch 0
0F Invalid position switch 1
10 CRC monitoring module list
11 Monitoring time range constant
12 SALI monitoring event
14 Extension unit has emergency bit set
15 Main unit has high emergency bit set
16 Program execution error
17 Slot list in extension module is faulty
18 System tick exceeded
19 Slot index error
1A Enter key not released while LED was flashing
1C External error hardware reset
1D Illegal error Opcode Reset
1E Error Clock generator reset
1F Unexpected reset
20 Unknown mask revisions
21 Error Clock generator loss of lock
41 Cross comparison input configuration erroneous
42 Cross comparison output state erroneous
81 Too many modules found
82 Unknown module ID found
83 Invalid jumper S1
84 Invalid jumper S2
85 Invalid jumper S3
86 Erroneous module configuration
87 Rotary switch changed during operation
88 Incomplete data frame on IndexAssign
