PROFINET IO Gateway
10.8 Error type definitions in PROFINET IO
T
he following table matches the PROFINET IO error type (as defined by the GSDML) to the
appropriate message.
Error type Message
0x106
Internal flex-bus error: Unknown SDO type (read, write). Power cycle Flexi Classic
system. Contact SICK service if problem persists.
0x107
Internal flex-bus error: Error on the reception of the data frame. Check for EMC
requirements. Contact SICK service if problem persists.
0x108
Internal flex-bus error: No frame bytes received. Power cycle Flexi Classic system.
Contact SICK service if problem persists.
0x109
Internal flex-bus error: Checksum error detected. Power cycle Flexi Classic system.
Contact SICK service if problem persists.
0x10a
Internal flex-bus error: No frame bytes received in the slave. Check connection
between modules. Contact SICK service if problem persists.
0x110
Internal flex-bus error: Data frame could not be sent. Power cycle Flexi Classic
system. Contact SICK service if problem persists.
0x111
Internal flex-bus error: Unknown error in RecFrameErrorCheck(). Power cycle Flexi
Classic system. Contact SICK service if problem persists.
0x112
Internal flex-bus error: Invalid frame revision received. Power cycle Flexi Classic
system. Contact SICK service if problem persists.
0x114
Internal flex-bus error: Continuous indexing check erroneous. Power cycle Flexi
Classic system. Contact SICK service if problem persists.
0x115
Internal flex-bus error: TX error: hold-register not clear. Power cycle Flexi Classic
system. Contact SICK service if problem persists.
0x116
Internal flex-bus error: Not all characters received within timeout. Power cycle Flexi
Classic system. Contact SICK service if problem persists.
0x117
Internal flex-bus error: SDO.cnt timeout. Power cycle Flexi Classic system. Contact
SICK service if problem persists.
0x118
Internal flex-bus error: Error in frame counter. Power cycle Flexi Classic system.
Contact SICK service if problem persists.
0x201
Internal resource error: Internal error in Delay (). Power cycle Flexi Classic system.
Contact SICK service if problem persists.
0x202
Internal resource error: Error on handling with T0. Power cycle Flexi Classic
system. Contact SICK service if problem persists.
0x203
Internal resource error: Error on deleting the flash page. Power cycle Flexi Classic
system. Contact SICK service if problem persists.
0x204
Internal resource error: Error in FlashWriteByte(). Power cycle Flexi Classic system.
Contact SICK service if problem persists.
0x205
Internal resource error: Timer management error in SAPL. Power cycle Flexi Classic
system. Contact SICK service if problem persists.
0x206
Internal resource error: Error on AdcStartSample(). Power cycle Flexi Classic
system. Contact SICK service if problem persists.
0x207
Internal resource error: Error on AdcDone(). Power cycle Flexi Classic system.
Contact SICK service if problem persists.
0x208
Internal resource error: Cross comparison SL-CRCs negative. Power cycle Flexi
Classic system. Contact SICK service if problem persists.
0x341
Internal program memory error: Flashtest error. Power cycle Flexi Classic system.
Contact SICK service if problem persists.
0x342
Internal program memory error: RAMtest error. Power cycle Flexi Classic system.
Contact SICK service if problem persists.
0x401
Self diagnostics error: System tick 1 ms exceeded in HAL SystemTickhandler().
Contact SICK service.
0x402
Self diagnostics error: System tick 4 ms exceeded. Contact SICK service.
0x403
Self diagnostics error: System tick 4.1 ms exceeded. Contact SICK service.
0x404
Self diagnostics error: Self test asynchronous. Contact SICK service.
0x405
Self diagnostics error: Error during cross comparison (Tx). Contact SICK service.
0x406
Self diagnostics error: Error during cross comparison (Rx). Contact SICK service.
0x407
Self diagnostics error: Error on watchdog relay (does not open). Contact SICK
service.
0x408
Self diagnostics error: Error on HAL_Synchronized. Contact SICK service.
0x409-0x41a
Self diagnostics error: Contact SICK service.
Tab.
120
:
PROFINET IO
error
types
