PROFINET IO Gateway
Error type Message
0x41b
Self diagnostics error: Error invalid bits in the output configuration. Contact SICK
service.
0x41c-0x4ff
Self diagnostics error: Contact SICK service.
0x501-0x5ff
Internal input test error: Internal test pulse not present on Ix. Contact SICK service.
0x601-0x6ff
External input test error: External test pulse not present on Ix. Check IO cabling.
Contact SICK service if problem persists.
0x701
Output test error: Output X1 not off. Check IO cabling for any cross circuits.
0x702
Output test error: Output X2 not off. Check IO cabling for any cross circuits.
0x703
Output test error: Cross-circuiting OSSD. Check IO cabling.
0x704
Output test error: Output X3 not off. Check IO cabling for any cross circuits.
0x705-0x707
Output test error: Short circuit on several outputs (bit mask). Check IO cabling.
0x708
Output test error: Output X4 not off. Check IO cabling for any cross circuits.
0x709-0x70f
Output test error: Short circuit on several outputs (bit mask). Check IO cabling.
0x710
Output test error: Output X1 not on. Check IO cabling for any short circuits.
0x711-0x71f
Output test error: Short circuit on several outputs (bit mask). Check IO cabling.
0x720
Output test error: Output X2 not on. Check IO cabling for any short circuits.
0x721-0x73f
Output test error: Short circuit on several outputs (bit mask). Check IO cabling.
0x740
Output test error: Output X3 not on. Check IO cabling for any short circuits.
0x741-0x77f
Output test error: Short circuit on several outputs (bit mask). Check IO cabling.
0x780
Output test error: Output X4 not on. Check IO cabling for any short circuits.
0x781-0x7ff
Output test error: Short circuit on several outputs (bit mask). Check IO cabling.
0x801
Voltage monitoring error: Undervoltage I/O. Check power supply.
0x802
Voltage monitoring error: Undervoltage power supply unit. Check power supply.
0x803
Voltage monitoring error: Undervoltage power supply unit and undervoltage I/O.
Check power supply.
0x804
Voltage monitoring error: Overvoltage I/O. Check power supply.
0x805-0x807
Voltage monitoring error: Refer to the user manual for further details on this error
code.
0x808
Voltage monitoring error: Overvoltage power supply unit. Check power supply.
0x809-0x81f
Voltage monitoring error: Refer to the user manual for further details on this error
code.
0x820
Voltage monitoring error: Error in power supply monitoring. Check power supply.
0x821-0x8ff
Voltage monitoring error: Refer to the user manual for further details on this error
code.
0x901
Configuration/diagnostics error: Modules incompatability. Check Flexi Classic
module revision and type for system requirements.
0x902
Configuration/diagnostics error: Configuration modification detected.
0x903-0x908
Configuration/diagnostics error: Refer to the user manual for further details on
this error code.
0x909
Configuration/diagnostics error: SDO client has invalid state. Contact SICK service.
0x90a
Configuration/diagnostics error: Unknown SDO-cnf. Contact SICK service.
0x90b
Configuration/diagnostics error: Unused SDO index. Contact SICK service.
0x90c
Configuration/diagnostics error: SDO #7 in slot list missing for at least one
module. Contact SICK service.
0x90d
Configuration/diagnostics error: Index error in slot list. Contact SICK service.
0x90e
Configuration/diagnostics error: Invalid position switch 0. Check switch settings.
0x90f
Configuration/diagnostics error: Invalid position switch 1. Check switch settings.
