Technical specifications
11.2 Technical specifications, supply circuit
T
hese technical specifications apply to all gateways.
Supply circuit (via e.g.
UE410-MU)
Min. Typ. Max.
Supply voltage 19.2 V DC
24 V DC
30 V DC
Power consumption 1.6 W
only UE410-EN: 2.4 W
11.3 Technical specifications application diagnostic outputs
These technical specifications apply to all gateways.
Application diagnostic
outputs (X1-X4)
Min. Typ. Max.
Type of output PNP semiconductors, short-circuit protected
Number of outputs 4
Switching voltage 18 VDC – 30 V DC
Switching current – – 100 mA
Total switching current 100 mA
Load capacity 100 nF
Cable length (single,
 1.5 mm²)
50 m
11.4 General technical specifications
These technical specifications apply to all gateways.
Terminals
X1, X2, X3, X4 Outputs, short circuit proof — supplied via Flexi Classic system
Fieldbus See section 11.1 “Technical specifications fieldbus”
FlexBus 10-pin connector for internal safety bus (plug)
Climatic conditions
Ambient operating temperature T
A
–25 to +70 °C
Storage temperature –25 to +70 °C
Relative humidity 10 to 95%, non-dewing
Climatic conditions (EN 61131-2)
Air pressure in operation 860 to 1060 hPa
