Chapter 4 Operating Instructions
Flexi Classic Gateways
30 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
PROFIBUS DP Gateway
4.2 Planning
4.2.1 GSD file
In the normal case the UE410-PRO is used on a DP master that looks up the device
characteristics in the so-called GSD file.
You will find the GSD file for PLC interfacing with Profibus support in the Internet at
www.ue410flexi.com.
The UE410-PRO provides at least 4 bytes of input data and 4 bytes of output data (2 bytes
of which are unused). The GSD identifier for this I/O module SCB1 Basic1 4 Byte in/out is
33h. If the DP master is configured with the aid of a GSD file, it is imperative this module is
included in the planning.
The UE410-PRO can provide further I/O modules as an option if included in the DP master
during the planning by the user. For more detailed diagnostics, the I/O module SCB2
Basic2 2 Byte in with the GSD identifier 11h is available.
A further optional I/O module is DIAG 10 Byte in with the GSD identifier 19h. Up to 4 units
of this module can be included in the planning.
There are therefore six possible ways of planning the UE410-PRO. Shown is the order of
the GSD identifiers for each plan:
Possible
planning
SCB1 Basic1
4 Byte in/out
SCB2 Basic2
2 Byte in
DIAG
10 Byte in
MED
13 Byte in
1 33h
2 33h 11h
3 33h 11h 19h
4 33h 11h 1Ch
5 33h 11h 19h 1Ch
UE410-PRO
