Chapter 3 Operating Instructions
Flexi Classic Gateways
14 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
Flexi Classic gateways
3.2.4 BAS1
Group error bits on the overall system and output data on the UE410-MU, UE410-MM and
UE410-GU.
Bit 7 6 5 4 3 2 1 Bit 0
UE410-MU
UE410-MM
QS AF ZF RO X1/2 X3/4
UE410-GU
IF
– – – –
FM
Q1 Q2
IF Internal error 0 = No internal errors
1 = An internal error has occurred on one of the
Flexi Classic modules
QS Cross circuit error
(not on UE410-GU)
0 = No cross circuit error
1 = Cross circuit error detected on an input pair
on the overall system
AF Process error
(not on UE410-GU)
0 = No process error
1 = A process error has occurred on one of the
Flexi Classic modules in a safety circuit
ZF Time error
(not on UE410-GU)
0 = No time error
1 = An internal error has occurred on one of the
Flexi Classic modules
RO EDM contacts open
(not on UE410-GU)
0 = No EDM error
1 = An error has occurred on the EDM contacts
on one of the modules. EDM contact was open
FM Program or function switch changed 0 = Switches have not been actuated
1 = Switches have been changed during
operation
X1/2 Outputs Q1/Q2
UE410-MU/MM
0 = Q1/Q2 inactive
1 = Q1/Q2 active
X3/4 Outputs Q3/Q4
UE410-MU/MM
0 = Q3/Q4 inactive
1 = Q3/Q4 active
Q1 Output Q1
UE410-GU
0 = Q1 inactive
1 = Q1 active
Q2 Output Q2
UE410-GU
0 = Q2 inactive
1 = Q2 active
3.2.5 BAS2
Output data from the A/B function groups on the UE410-XU main module, the UE410-8DI
expansion modules and the UE410-XM, UE410-MDI muting modules.
Bit 7 6 5 4 3 2 1 Bit 0
MOD2 MOD3 MOD4 MOD5
Tab.
5
:
BAS1
Tab.
6
:
BAS2
