SICK Flexi Classic User Manual

Chapter 6 Operating Instructions
Flexi Classic Gateways
50 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
DeviceNet Gateway
6.2 Planning
6.2.1 EDS file
The EDS (Electronic Data Sheet) is read once into the device database for the DeviceNet-
Manager
TM
. For this purpose the menu command “Utilities/Read EDS Files” is to be used.
For planning use the DeviceNetManager
T
M
from Allen Bradley. You will find the EDS file in
the Internet at www.ue410flexi.com.
Data direction
Byte
Read Write
1 CRC1 DIG-OUT
2 CRC1 REQ-id
3 BAS1 -
4 BAS2 -
5 BAS3 -
6 BAS4 -
7
B1 -
8
B2 -
9
B3 -
10
B4 -
11
B5 -
12
B6 -
13
B7 -
14
B8 -
15
B9 -
16
B10 -
6.2.2 Diagnostics data UE410-DEV
You will find the system and diagnostics data in the section 3.2 “Status information of all
Flexi Classic gateways (system bytes)”.
Tab.
59
:
Format of the
diagnostics data UE410-DEV
