Chapter 3 Operating Instructions
Flexi Classic Gateways
18 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
Flexi Classic gateways
O
P
, O
N
(only UE410-GU)
Communication for global
emergency stop to the previous or
next module
0 = Global emergency stop is
inactive
1 = Global emergency stop is
active
MUTE Status bit for Muting 0 = Muting is inactive
1 = Muting is active
BYP Status bit for Bypass 0 = Bypass is inactive
1 = Bypass is active
3.2.13 MKD1
Module configuration data 1: Position of the program switch/function switch/time range
(not UE410-GU)
Bit 7 6 5 4 3 2 1 Bit 0
SW1 SW2
SW1 Top switch setting 0-9
SW2 Bottom switch setting 0-9
3.2.14 MKD2
Module configuration data 2: (UE410-MU/XU configuration on S1, S2, S3)
(UE410-MM/XM: configuration on S1)
(not UE410-GU)
Bit 7 6 5 4 3 2 1 Bit 0
UE410-MU
UE410-XU
– S3 S2 S1
UE410-MM
UE410-XM
– – – S1
S1 Configuration jumper on S1 00 = Open
S2 Configuration jumper on S2 01 = On X1
10 = On X2 S3 Configuration jumper on S3
11 =
Active at +U
B
Tab.
14
:
MKD1
Tab.
15
:
MKD2
