Chapter 3 Operating Instructions
Flexi Classic Gateways
22 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
Flexi Classic gateways
ErrCode for ErrClass 07h:
M 01 Output X1 not off (cross circuit)
M 02 Output X2 not off (cross circuit)
M 03 Cross-circuiting OSSD
M 04 Output X3 not off (cross circuit)
M 08 Output X4 not off (cross circuit)
M 10 Output X1 not on (short circuit)
M 20 Output X2 not on (short circuit)
M 40 Output X3 not on (short circuit)
M 80 Output X4 not on (short circuit)
(M = Bit mask; several errors can occur simultaneously)
ErrCode for ErrClass 08h:
M 01 I/O undervoltage
M 02 Power supply undervoltage
M 03 Undervoltage power supply unit and undervoltage I/O
M 04 I/O overvoltage
M 08 Power supply overvoltage
M 20 Error power supply monitoring
(M = Bit mask; several errors can occur simultaneously)
