Operating Instructions Chapter 3
Flexi Classic Gateways
8011834/YT28/2016-03-15 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
21
Subject to change without notice
Flexi Classic gateways
ErrCode for ErrClass 04h:
01 System tick 1ms exceeded in HAL SystemTickhandler()
02 System tick 4 ms exceeded
03 System tick 4_1 ms exceeded
04 Self-test asynchronous
05 Error during cross comparison (Tx)
06 Error during cross comparison (Rx)
07 Error on watchdog relay (does not open)
08 Error on HAL_Synchronized
1B Error invalid bits in the output configuration
ErrCode for ErrClass 05h:
M 01 Internal test pulse not present on I1
M 02 Internal test pulse not present on I2
M 04 Internal test pulse not present on I3
M 08 Internal test pulse not present on I4
M 10 Internal test pulse not present on I5
M 20 Internal test pulse not present on I6
M 40 Internal test pulse not present on I7
M 80 Internal test pulse not present on I8
(M = Bit mask; several errors can occur simultaneously)
ErrCode for ErrClass 06h:
For base module
M 01 External test pulse not present on I1
M 02 External test pulse not present on I2
M 04 External test pulse not present on I3
M 08 External test pulse not present on I4
M 10 External test pulse not present on I5
M 20 External test pulse not present on I6
M 40 External test pulse not present on I7
M 80 External test pulse not present on I8
For muting input extension:
M 01 External test pulse not present on I1
M 02 External test pulse not present on I2
M 04 External test pulse not present on I3
M 08 External test pulse not present on I4
(M = Bit mask; several errors can occur simultaneously)
