Page #110 background imageLoading...
Page #110 background image
Chapter 9 Operating Instructions
Flexi Classic Gateways
110 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8011834/YT28/2016-03-15
Subject to change without notice
EtherNet/IP Gateway
Attribute number Data set parameter Size
33 MS Byte=MFCLASS2, Module 9
LS Byte=MFCODE2, Module 9
UINT
34 MS Byte=MFCLASS1, Module 10
LS Byte=MFCODE1, Module 10
UINT
35 MS Byte=MFCLASS2, Module 10
LS Byte=MFCODE2, Module 10
UINT
36 MS Byte=MFCLASS1, Module 11
LS Byte= MFCODE1, Module 11
UINT
37 MS Byte=MFCLASS2, Module 11
LS Byte=MFCODE2, Module 11
UINT
38 MS Byte=MFCLASS1, Module 12
LS Byte=MFCODE1, Module 12
UINT
39 MS Byte=MFCLASS2, Module 12
LS Byte=MFCODE2, Module 12
UINT
40 MS Byte=MFCLASS1, Module 13
LS Byte=MFCODE1, Module 13
UINT
41 MS Byte=MFCLASS2, Module 13
LS Byte=MFCODE2, Module 13
UINT
Instance 6 - data set 6 attribute definitions
Attribute number Data set parameter Size
2 CRC (System) UINT
3 MKD1, Module 1 SINT
4 MKD2, Module 1 SINT
5 MKD1, Module 2 SINT
6 MKD2, Module 2 SINT
7 MKD1, Module 3 SINT
8 MKD2, Module 3 SINT
9 MKD1, Module 4 SINT
10 MKD2, Module 4 SINT
11 MKD1, Module 5 SINT
12 MKD2, Module 5 SINT
13 MKD1, Module 6 SINT
14 MKD2, Module 6 SINT
15 MKD1, Module 7 SINT
16 MKD2, Module 7 SINT
Tab.
104
:
Individual Data Set
Transfer Object (73hex)
instance 6 attribute
definitions
