EtherNet/IP Gateway
Instance attributes
Attribute ID Name Data type Data value(s) Access rule
3 Set Digital
Output
SINT 0 = Off
1 = On
Set
4 Get Digital
Output Setting
SINT 0 = Off
1 = On
Get
Description of instance IDs
Instance ID Description
1 Digital Output X1
2 Digital Output X2
3 Digital Output X3
4 Digital Output X4
Common services
Service code Implemented in class Implemented in
instance
Service name
0Ehex Yes Yes Get_Attribute_Single
10hex No Yes Set_Attribute_Single
Tab.
107
:
Discrete Output
Point Object Definition
(09hex) instance attributes
Tab.
108
:
Discrete Output
Point Object Definition
(09hex) description of
instance IDs
Tab.
109
:
Discrete Output
Point Object definition (09hex)
common services
