Ethernet TCP/IP Gateway
Configuration via TCP/IP interface
This command message is sent by an application to the UE410-EN to configure the Auto
U
pdate Mode. This message can be used to either disable or enable the Auto Update
Mode directly through the TCP/IP interface.
Parameter Length Value
Command WORD 00E1Hex = Auto-Update Control
Request Data
Set 1
WORD 0 = Do not send Data Set 1
1 = Send Data Set 1
Request Data
Set 2
WORD 0 = Do not send Data Set 2
1 = Send Data Set 2
Request Data
Set 3
WORD 0 = Do not send Data Set 3
1 = Send Data Set 3
Request Data
Set 4
WORD 0 = Do not send Data Set 4
1 = Send Data Set 4
Request Data
Set 5
WORD 0 = Do not send Data Set 5
1 = Send Data Set 5
Request Data
Set 6
WORD 0 = Do not send Data Set 6
1 = Send Data Set 6
Sequential
Number
WORD Initial sequential number for Auto-Update messages.
Heartbeat Mode
Update Rate
WORD 0 = Disable Heartbeat Messages
Non-zero = Enable Heartbeat Message at specified rate in ms.
Minimum = 200 ms
Save in Flash WORD 0 = Do not save in flash
1 = Save in flash
The response message returned to the application by the UE410-EN:
Parameter Length Value
Command WORD 001Ehex = Response to the Auto-Update control message
Sequential
number
WORD Response sequential number (same as sent in the command
message)
Status WORD 0 = Success — Write to flash successful
1 = Error writing to flash
Tab.
75
:
Auto Update Mode
configuration command
Tab.
76
:
Auto Update Mode
configuration response
