SICK Flexi Soft User Manual

UE410-2RO/UE410-4RO
Wire cross-section Single-wire or fine-stranded wire: 0.2 … 1.5mm²
St
randed wire with ferrule:
a) With plastic ferrule max. 0.75mm²
b) Without plastic ferrule max. 1.5mm²
AWG to UL/CUL: 24 … 16
Stripping length Max. 8mm
Tightening torque Max. 0.6Nm
For UL-508 and CSA applications
UE410-xx3…, UE410-
xxx3…
Cross-sectional area AWG 30-12
(use onl
y 60/75°C copper wire)
Tightening torque 5-7lb⋅in
UE410-xx4…, UE410-
xxx4…
Cross-sectional area AWG 30-12
(use only 60/75°C copper wire)
Electrical data
T
able 183: Input circuit (B1, B2) of the UE410-2RO/UE410-4RO
Minimum Typical Maximum
Input voltage ON 18V DC – 30V DC
Table 184: Output circuit (13-14, 23-24, 33-34, 43-44) of the UE410-2RO/UE410-4RO
Minimum Typical Maximum
Number of normally open contacts
UE410-2RO 2
UE410-4RO 4
Number of N/C contacts
UE410-2RO 1
UE410-4RO 2
AC switching voltage 5V AC 230V AC
1)
253V AC
DC switching voltage 5V DC 230V DC
1)
253V DC
Switching current 10mA – 6A
Mechanical service life Min. 10 ×10
6
Electrical endurance see figure 69, page 169
Minimum contact load at U
n
= 24V
DC
50mW – –
Sum current – – 8A
Response time
2)
– – 30ms
Type of output Volt-free normally open contacts, positively guided
Contact material AgSnO
2
Output circuit protection 6A gG, per current path
Utilization category AC-15: U
e
250V
, I
e
3A
DC-13: U
e
24V
, I
e
3A
1)
see figure 68, page 169 or see
figure 69, page 169.
2)
Time from low at B1/B2 to drop out of relay.
12 T
ECHNICAL DATA
168
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice

SICK Flexi Soft Specifications

General

Safety Integrity Level (SIL)	SIL3
Performance Level (PL)	PL e
Programming	Flexi Soft Designer
Power Supply	24 V DC
Safety Protocols	PROFIsafe, CIP Safety
Protection Class	IP20
Number of I/Os	Configurable
Operating Voltage	24 V DC
Power Consumption	Depends on configuration
Dimensions (W x H x D)	Varies depending on the module configuration
Weight	Varies depending on the module configuration
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Safety Standard	IEC 61508, IEC 62061, ISO 13849
Operating Temperature	0°C to +55°C
Response Time	< 10 ms (typical)
Storage Temperature Range	-25°C to +70°C
Relative Humidity	15 % ... 95 %, non-condensing
