Installation
Dimensions (W x H x D) See dimensional drawings (→ p. 155, §9.6)
Weight See dimensional drawings (→ p. 155, §9.6)
Material in contact with media Aluminium AC-42100-S-T6
Mounting Horizontal or vertical installation with 0 D straight inlet/outlet piping
Electrical connection
Voltage Intrinsically safe supply: 4.5 ... 16 V DC
Including 3-months backup battery
Power input ≤ 100 mW
General
Options Self-sufficient meter design (typical battery service life: More than 5 years)
Scope of delivery The scope of delivery is dependent on the application and the customer
specification.
General
Battery type Battery pack 2R6 → 6049966 Tadriran SL-860
Battery pack 2R20 → 6050492 Tadiran SL-2880
Battery chemistry Lithium thionyl chloride cell → Li/SOCl2
[1] Volume flow a.c. according to AGA 9
DN50/2": 1.6 ... 160 m³/h (57 ... 5,650 cfh)
DN80/3": 4.0 ... 400 m³/h (141 ... 14,125 cfh)
DN100/4": 6.5 ... 650 m³/h (230 ... 22,955 cfh)
DN150/6": 6.5 ... 1.000 m³/h (230 ... 35,314 cfh)
Table 35 Technical Data (additional for device option volume conversion)
Volume conversion
Accuracy Accuracy class 0.5
Maximum allowed error limit of conversion factor C: ≤ ± 0.5%
(at reference conditions)
Conversion method PTZ or TZ
Calculation methods
● Fixed value
● SGERG88,
● AGA 8 Gross method 1
● AGA 8 Gross method 2
● AGA NX-19
● AGA NX-19 mod.
● AGA NX-19 mod. GOST
● GERG91 mod.
● AGA8-92DC (AGA-8 detail)
Logbooks and Archives
Logbooks
● Event logbook (1000 entries)
● Parameter logbook (250 entries)
● Metrology logbook (100 entries)
● Gas composition logbook (150 entries)
Archives
● Billing archive (6000 entries)
● Day archive (600 entries)
● Month archive (25 entries)
Pressure sensor (only for device option volume conversion)
Measuring ranges Absolute pressure sensors Relative pressure sensors
0.8 ... 5.2 bar (a) 0 ... 4 bar (g)
2.0 ... 10.0 bar (a) 0 ... 10 bar (g)
4.0 ... 20.0 bar (a) 0 ... 20 bar (g)
0.8 ... 20.0 bar (a)
Temperature sensor (only for device option volume conversion)
Measuring ranges -25 ... +60 ° C
-40 ... +70 ° C (optional)
