Product description
FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH 35
Subject to change without notice
Fig. 9 Seals on the terminal compartment and plug-in connector cover
Fig. 10 Seal on the temperature sensor (example)
NOTICE:
▸ Secure the terminal compartment cover and the plug-in connector cover
with at least one verification seal against unauthorized removal of the
cover!
1
2
1 Seal position
2 Terminal compartment cover (securing the terminal compartment)
3 Plug-in connector cover
4 Capstan screw, wire and wire seal (securing of plug-in connector cover)
3
4
1 Temperature sensor
2 Locknut
3 Wire seal
3
2
1
