Installation
FLOWSIC500 · Operating Instructions · 8025733/1GMJ/V4-2/2022-07 · © SICK Engineering GmbH 41
Subject to change without notice
Table 9 Gaskets
Device/flange type
Da
[1]
[mm] Di [mm] S [mm]
Material
PN16 / EN1092-1
DN50/ PN16 107 61
2 novapress® FLEXIBLE/815
DN80/ PN16 142 90
DN100/ PN16 162 115
DN150/ PN16 218 169
Class 150 / ASME B16.5
2"/ Cl150 105 60
2 novapress® FLEXIBLE/815
3"/ Cl150 137 89
4"/ Cl150 175 114
6"/ Cl150 222 168
[1] Da = outer diameter, Di = inner diameter, S = thickness, → Fig. 12
