ABOUT THIS MANUAL 1
1About this Manual
1.1 Target group of this Manual
The actions and measures described in this Manual are intended exclusively for trained
and authorized service technicians of SICK AG and their representatives.
1.2 Purpose of this Manual
This Manual serves as guide for the following tasks on the MCS200HW:
● Maintenance
● Clearing malfunctions “on site and with common tools”.
This Manual is only complete in combination with the Operating Instructions of the
MCS200HW. Availability and knowledge of the MCS200HW Operating Instructions is
assumed.
The technical layout of your MCS200HW can differ from the version described in this
Manual due to changes made by the manufacturer or customer.
▸ When necessary, clarify with the customer and/or SICK AG Helpdesk the correct state
the MCS200HW should be in.
1.3 Information concerning this Manual
Basic knowledge of handling SOPAS is required. The SOPAS project tree and the SOPAS
menu are referred to in some Chapters. The SOPAS project tree refers to the current
directory structure on the left side in SOPAS. The SOPAS menu refers to the menu line in
SOPAS. Furthermore, operating the operator panel is not described here. Handling the I/O
modules is also not explained in detail.
Intervention on the MCS200HW by unauthorized persons voids the guarantee by the
SICK AG.
WARNING: Damage as a result of improper working
Improper working can damage health and equipment and affect measuring precision.
Corrosive, toxic or caustic gases can escape depending on the sample gas composition.
● The actions and measures described in this Manual may only be carried out by
trained and authorized Service technicians of SICK AG and their representatives,
who have been professionally trained and are qualified appropriately on the device
and for the following tasks.
–Working with gas analyzers
– Mechanical installations
– Electrical installations
– Making and testing gas-tight connections
– Handling technical gases
Do not carry out any work on the MCS200HW without previous training.
This Manual is intended exclusively for trained service personnel and is not an
instruction manual.
If you have questions concerning this Manual, if there is something you do not under-
stand or whenever something is missing:
▸ Please contact the SICK AG Helpdesk.
