5 REPAIRS
5.3.4 Fitting the complete sender/receiver unit
1 Push sheet metal cover 1 in with foam insulation.
2 Insert the sleeves and tighten sheet metal cover 5.
3 Attach sheet metal covers 4 to 2.
4 Screw all sheet metal covers tight.
5 Fit the outer sheet (see Fig. 140 “Sender/receiver unit, outer plate”, page 96):
▸ Guide the power supply cable through the recess.
▸ Tilt the sheet slightly when attaching.
6 Connect the hose connections of the sender/receiver unit to the outer sheet.
7 Attach the inner bracket and screw tight (see Fig. 138 “Transmit/receive unit, front
side”, page 95).
8 Screw the templates tight on the rear side (see Fig. 137 “Sender/receiver unit, rear
side”, page 95).
9 Hook the sender/receiver unit with the mushroom head brackets into the device
cabinet.
10 Screw the sender/receiver unit tight on the device cabinet (see Fig. 136 “Sender/
receiver unit, fastening screws”, page 94).
11 Connect the plug connections.
12 Screw the electronics housing cover tight.
13 Replace the drying agent (see Chapter “Replacing the drying agent”, page 44).
14 Close the cover of the sender/receiver unit (optional) and screw tight.
5.3.5 Replacing the fan
1 Disconnect the MCS200HW power supply.
2 Remove the electronics housing cover and fan cover (see Chapter “Removing the elec-
tronics housing cover”, page 88).
3 Disconnect the fan power supply.
Tools required
Phillips screwdriver
6 mm Allen key
2.5 mm Allen key
Tweezers
Tools required
Phillips screwdriver
Spare parts set No. Contents
2099749 Fan with filter unit for electronics unit
