SICK MCS200HW Service Manual

52
8024638/AE00/V1-0/2019-09| SICKSERVICE MANUAL | MCS200HW
Subject to change without notice
5 REPAIRS
5Repairs
5.1 Working on the device cabinet
Fig. 59: Equipment cabinet, inside
5.1.1 Replacing the door fan
1 Disconnect the MCS200HW power supply.
2 Disconnect the power supply of the door fan.
1 Heated sample gas line
2 Roof ventilator
3Valve manifold
4IO modules
5 Pressure reducer unit
6Cell
7Test gas line
8Sender/receiver unit
9Electronics unit
Tools required
Phillips screwdriver
Spare parts set No. Contents
6048627 Door fan
