Siemens SICAM RTU User Manual

System Components
SICAM RTUs, SICAM AK 3 User Manual 117
DC2-028-2.03, Edition 07.2016
2.5.2.6 Return Information to Pulse Command Assignment
Predefined assignment to PCCO26 (assigning commands without building groups)
Type Predefined assignment
Single information to single
command
(1-pole, 1.5-pole)
SI D00…command CA00
SI D01...command CA01
:
SI D31…command CA31
SI D32…command CB00
SI D33…command CB01
 :
SI D63…command CB31
Single information to single
command
(2-pole)
SI D00…command CA00/CB00
SI D01…command CA01/CB01
:
SI D31…command CA31/CB31
Double information to double
command
(1-pole, 1.5-pole)
DI D00/D01…command CA00/CA01
DI D02/D03…command CA02/CA03
:
DI D30/D31…command CA30/CA31
DI D32/D33…command CB00/CB01
DI D34/D35…command CB02/CB03
:
DI D62/D63…command CB30/CB31
Double information to double
command
(2-pole)
DI D00/D01…command CA00..CB01
DI D02/D03…command CA02..CB03
:
DI D30/D31…command CA30..CB31
Predefined assignment to PCCO27 (assigning commands in groups)
Type Predefined assignment
Single information to single
command
(1-pole, 1.5-pole)
SI D00…command CA00
SI D01…command CB00
SI D02…command CA01
SI D03…command CB01
:
SI D62…command CA31
SI D63…command CB31
Single information to single
command
(2-pole)
SI D00…command CA00/CB00
SI D02…command CA01/CB01
:
SI D60…command CA30/CB30
SI D62…command CA31/CB31
Double information to double
command
(1-pole, 1.5-pole)
DI D00/D01…command CA00/CB00
DI D02/D03…command CA01/CB01
:
DI D62/D63…command CA31/CB31
Double information to double
command
(2-pole)
DI D00/D01…command CA00..CB01
DI D04/D05…command CA02..CB03
:
DI D56/D57…command CA28..CB29
DI D60/D61…command CA30..CB31
