Siemens SICAM RTU User Manual

Automation Units and Automation Networks
SICAM RTUs, SICAM AK 3 User Manual 251
DC2-028-2.03, Edition 07.2016
6.3.3 Example A
This example shows the usage of 2 static routes from a SICAM AK 3 via 2 gateways to control
center in different IP networks.
Routing table from SICAM TOOLBOX II
SICAM AK 3
Substation Zone
SICAM AK SICAM AK
CP-2016
Office Zone
Control Center Zone 1
IEC 61850
60870-104
Office Zone
Control Center Zone 2
IEC 61850
60870-104
Control Center B
: 255.255
IP address:
Subnet mask
172.16.50.2
.255.0
Control Center D
: 255.255
IP address:
Subnet mask
172.16.51.2
.255.0
IP address:
Subnet mask
172.16.50.100
.255.0: 255.255
Cisco Router
: 255.255
Gateway IP address - Route 0
IP address:
Subnet mask
192.168.94.250
.255.0
IP address:
Subnet mask
172.16.51.100
.255.0: 255.255
Control Center A
: 255.255
Destination IP address - Route 0
IP address:
Subnet mask
172.16.50.1
.255.0
CP-2016 or CP-2019
Master Modul:
1 IP Addresse
192.168.94.1
255.255.255.0
192.168.94.250
Mode der Ethernet Ports
Own IP address
......
..................
..............................
.....................
Subnet mask
Default gateway
X0:
Source IP address - Static route 0
Source IP address
Source IP address
..........
..........
192.168.94.1
192.168.94.1
Source IP address - Static route 1
Static route 1
Static route 0
Control Center C
: 255.255
Destination IP address - Route 1
IP address:
Subnet mask
172.16.51.1
.255.0
Cisco Router
: 255.255
Gateway IP address - Route 1
IP address:
Subnet mask
192.168.94.251
.255.0
