6.1.1.5 SICAM AK 3 - SICAM AK 3 PE, electrical and optical
Basic unit SICAM AK 3 to SICAM TM peripheral elements, electrically and optically connected
• To one basic system element CP-2016/CPCX26 or CP-2019/PCCX26 one bus line with
max. 16 peripheral elements can be connected.
• Depending on the slot of the basic system element the socket connector for the electrical
Ax 1703 peripheral bus has to be selected.
(for example: Slot 1 ð socket connector X4/C1-Ax)
SI CAM AK
PS-263x
SI CA M AK
PS-263x
CP-2016 DI-2110DO-2210 AI-2300CP-2019 AI-2301 DI-2110 DI-2110 DO-2210 AI-2300CP-2019 AI-2301AI-2301 DI-2110DI-2110 DI-2110
CP-2016
CP-2019
PE-6410
PS-663x
PE-6411
PS-663x
3
3
3
2
2
S
I
C
A
M
1
7
0
3
S
I
C
A
M
1
7
0
3
ON
OFF
S1
1
1
SICAM AK 3
base unit
I/O modules (max. 8)
Ax 1703 peripheral bus (electrical)
16 Mbps
patch-cable, length up to 3 m
Ax 1703 peripheral bus
(optical)
16 Mbps
FO, length up to 200 m
I/O modules (max. 8)
Ax 1703 peripheral bus
(electrical), 16 Mbps
USB-cable, length up to 3 m
bus interface modules
CM-0843
1 peripheral element
1 peripheral element
bus interface
modules CM-0842
SICAM TM
peripheral elements
(max. 16)
Settings on the
configuration switch S1
