Engineering via SICAM TOOLBOX II
200 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
4.2.1 Create Function Diagram (FUD)
For the creation of a function diagram the tool "CAEx plus" is required.
4.2.1.1 Configuring External Signals
The I/O's are integrated into the Function Diagram via the Signal List. Dependent from the
fact, whether the target system is engineered via the SICAM TOOLBOX II or via the web
browser, the Signal List can be alternatively
• generated with the tool "OPM II"
• imported from a local parameterization (see thereto section 4.1.7, Import, Export and
Backup of Engineering Data)
The signals of the process-technical plant can be used by CAEx plus after the transformation
(refer to section 4.1.6, Transform Parameters). The structure of the project tree automatically
adapts to the structure from the OPM II.
An introduction how to create a project can be found in the TOOLBOX II CAEx plus Online
Help chapter "First Steps" and chapter "Additional Products", section "Signal List (Optional)".
