Siemens SICAM RTU User Manual

Automation Units and Automation Networks
250 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
6.3 Application/Configuration of Static Routes
6.3.1 General
Static routing is based on a fixed definition of the path of data packages between two end sys-
tems. This definition is written down by administrators in a routing table. This kind of routing
serves for security, respectively is used in network configurations, if several default gateways
are used. Because of the big effort for the manual maintaining of the tables the number of
routes is restricted.
CP-2016 CP-2019
• Number of static routes
10 10
• Parameter of static routes
− Source IP address
P P
− Destination IP address
P P
− Gateway IP address
P P
− Subnet mask
P P
• Interfaces
X0, X1 X0, X1
6.3.2 Configuration
Activation of the „static routes“
• Parameter Network settings | IP address | advanced parameters | Enable
static routes = YES
Definition of the routing table
• Parameter Network settings | IP address | advanced parameters | static
routes = Number of lines x (max. 10)
Mode of the Ethernet Ports
• Parameter Network settings | IP address | Mode of ethernet ports = 1 IP
address (connected ports in switch mode)
The data packages are sent via the interfaces X0 and X1.
• Parameter Network settings | IP address | Mode of ethernet ports = 2 IP
addresses (independent ports)
The data packages are sent via that interface (X0 or X1) to which the respective source IP
address (Own IP address X0 or Own IP address X1) is assigned.
