Siemens SICAM RTU User Manual

Service
218 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
5.2.3 Peripheral Elements
Startup (step) RY ER Error
Reset, power up or startup initiat-
ed by the higher-level system
element
™
˜
*)
Module defect
Check code memory (flash
PROM)
™
˜
*)
PROM error (code)
• Module is shutdown
• Startup is aborted
Check data memory (RAM)
™
˜
*)
RAM error (data)
• Module is shutdown
• Startup is aborted
Reception of the parameters from
the higher-level system element
™
™
*)
Too little memory
• Firmware is shutdown
• Startup is aborted
Check of the parameter contents
™
™
*)
Parameter error
• Diagnosis information is set
Startup concluded without error
˜ ™
Startup concluded with error
˜ ˜
*)
in addition the system-LED "ER" lights up on the basic system element
Error (startup aborted) RY ER Note
Module defect
™
˜
*)
Exchange system element
PROM error (code)
™
˜
*)
Exchange system element
RAM error (data)
™
˜
*)
Exchange system element
Too little memory
™
§
*)
SICAM TOOLBOX II diagnosis
Parameter error
™
˜
*)
SICAM TOOLBOX II diagnosis
*)
in addition the system-LED "ER" lights up on the basic system element
Error (startup continued) RY ER Note
Parameter error
˜
˜
*)
SICAM TOOLBOX II diagnosis
*)
in addition the system-LED "ER" lights up on the basic system element
