Siemens SICAM RTU User Manual

System Components
152 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
Connecting Resistance Thermometers in 4-Wire Technology
2.7.4 SM-0572
The SM-0572 submodule (analog output extension 2x ±20 mA/±1 V/±10 V) provides two ana-
log outputs.
Pt100 / Ni100
Pt100 / Ni100
+
-
SM-0571
+
-
I/O 1
IN IREF0+
IN V0+
IN V0-
IN IREF0-
IN IREF1+
IN V1+
IN V1-
IN IREF1-
I/O 3
I/O 2
I/O 0
I/O 7
I/O 5
I/O 4
I/O 6
SICAM RTUs
carrier module
internal
interface
SM-0572
2 analog outputs
