Page #168 background imageLoading...
Page #168 background image
Prepare Engineering
168 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
3.1 Engineering Tool SICAM TOOLBOX II
SICAM AK 3 is parameterized with a PC on which the SICAM TOOLBOX II software is in-
stalled. For this, the SICAM TOOLBOX II PC and automation unit must be connected with
each other and a SD card installed on the master control element (CP-2014).
3.1.1 Software for the Engineering
The SICAM TOOLBOX II is available on DVD ROM and consists of the following toolsets:
EM II
Engineering Manager (base package)
PSR II
Engineering and Maintenance Computer
OPM II
Object Oriented Process Data Manager
CAEx plus
Tool for the creation of an application program as function diagram (FUD), structured text
(ST), sequential function chart (SF)
Alternatively, an existing and compatible instruction list (IL) can be stored in the SICAM
TOOLBOX II.
The toolsets are also available as “Light” version. With this version, the engineering is limited
to maximal 100 system elements and 2000 data points.
The toolsets are available individually. You find information and updates for the individual
toolsets, as well as numerous licenses, in the Internet under www.siemens.com/sicam.
Document Designation Item Number
Licences, variants and order
form
SICAM TOOLBOX II V5 license catalog,
license demand
D30-017-5
