Engineering via SICAM TOOLBOX II
204 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
4.2.3 Commissioning and Test
4.2.3.1 Loading Program Code
To load the program code (compiled FUD) into the target system, the engineering PC must be
connected with the target system (see 3.2, Connect Engineering PC with a Target System).
The loading of the program code into the target system takes place jointly with the parameters
set in the "OPM II". Thereto the tool "Parameter Loader" must be used (see also section
4.1.9.1, Loading Engineering Data).
Caution
During a loading operation, a power down of the master control element is to be absolutely avoided, since
the data on the flash card could be destroyed as a result.
You find the technical description thereto in the manual SICAM RTUs Common Functions
System and Basic System Elements, chapter "Automation", section "Open-/Closed-Loop Con-
trol Function", "Loading of Application Program (Reload)".
You find the instruction for the operation in the SICAM TOOLBOX II Online Help, chapter
"Service Programs", section "Parameter Loader".
Note
Instead of a function diagram an instruction list (ASCII format) can be imported in "CAEx plus".
4.2.3.2 Test Functions
4.2.3.2.1 Simulate Function Diagram Offline
The logic operations of a function diagram can be tested in "CAEx plus" with the offline
Simulation.
This function can be called via the context menu of the basic system element, program in-
stance or type instance (right mouse button). You can find the details thereto in the CAEx plus
User Manual, chapter "Additional Products", section "Offline Simulation".
