Siemens SICAM RTU User Manual

Installation
58 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
1.4.5.1.7 Serial communication – Direct connection with RS-232
Serial communication connection between SICAM AK 3 and other automation units with a
cross-over RS-232 connection cable.
The "cross-over" of the RS-232 interface signals can be made on SICAM AK 3 with the long
“RJ45 Cable assembly 10m“ j or the short “Cross Over Adapter RJ45“ k.
If the "cross-over" of the RS-232 interface signals is made on the remote station (e.g.: on
SICAM AK and SICAM TM with CM-2868), then you can connect the connection cable (patch
cable) directly l to SICAM AK 3.
Accessories see SICAM AK 3 System Description, chapter „Order Information“.
C P - 2016 C P - 2019
X0
X1
X2
X3
X0
X1
X2
X3
SICAM T M170 3AC P C P-60 14
X1
X11 X4 X12 X 14 X16
X15
X13
WD ER
X5
X3 X6 X10
SIM1
/PK
/LK /LK
/PK RXERx TX
SI 3 SI 2 SI 1 SI 0 LO C
FB
M-PR E/3 NC
TB
NC
PWR 24-60VDC
SYNC
PUSHTO UNLOCK
ER
COM
CPY
RY RE S
SI3
REL EASE PUSHTO
RELEASE PUSHTOX2
1 2 3 4 5 6
Patch Plug CM-2860
SICAM TM
SM-2551, SM-2541
or
SM-0551 on SM-2558
Patch cable
1 2 3
CP-2016
with SM-0551
on SM-2558
CP-2019
with SM-2551
Patch cable
Cross Over
Adapter RJ45
RJ45 Cable
assembly 10m
CM-2868
2868 2860 2860
