Page #232 background image
Service
232 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
5.5.1.3.1 Load Firmware Online
Thereto the SICAM TOOLBOX II PC must be connected with the target system. For the exe-
cution, the configuration possibilities listed under section 3.2, Connect Engineering PC with a
Target System are applicable.
With the tool "Load Firmware" ( SICAM TOOLBOX II | Service Programs ) you can load
firmware codes into the target system. The following options are available:
Load intelligent
The latest firmware revision available in the SICAM TOOLBOX II is loaded, if it is more
current than that one on the corresponding system element
Load unconditional
The latest firmware revision available in the SICAM TOOLBOX II is loaded
After startup, the target system loads the respective firmware on the corresponding system el-
ement. Additionally it stores the firmware on the SD card.
Note
For the online loading the SD card and a running firmware must be present on the master control element
of the target system. Further, you need the appropriate access right for the engineering tool.
You find the instructions for the tool "Load Firmware" in the SICAM TOOLBOX II Online Help,
chapter "Service Programs", section "Load Firmware".
5.5.1.3.2 Load Firmware Offline
Thereto a SD card reader/writer must be connected on the SICAM TOOLBOX II PC, and a
suitable SD card must be inserted.
With the tool "OPM II" you can select the corresponding AE via the menu Tools | System
technique . Via the context menu of the automation unit Flashcard | create files… you
can transfer firmware files on a SD card.
You find the details thereto in the SICAM TOOLBOX II Online Help, chapter "OPM II", section
"System technique | SICAM RTUs | Load Flashcard".
After that, insert the SD card into the master control module, and insert that into the target
system. The target system performs a startup, and loads thereby the firmwares on the corre-
sponding system elements.
Note
The first loading of the firmware (initialization) of the master control element is only offline possible.
