2.5.4.5 I/O Assignment
The assignment of the HW pins to the data points is done according to the following scheme.
2.5.4.5.1 Outputs
Pulse Commands - PCCO26
HW pin Data point
Single command 1-pole and 1½-pole
CA00
CA01
CA02
:
CA31
Command CA00 (RI:SI D00)
Command CA01 (RI:SI D01)
Command CA02 (RI:SI D02)
:
Command CA31 (RI:SI D31)
CB00
CB01
:
CB31
Command CB00 (RI:SI D32)
Command CB01 (RI:SI D33)
:
Command CB31 (RI:SI D63)
Single command 2-pole
CA00 / CB00
CA01 / CB01
:
CA30 / CB30
CA31 / CB31
Command CA00/CB00 (RI:SI D00)
Command CA01/CB01 (RI:SI D01)
:
Command CA30/CB30 (RI:SI D30)
Command CA31/CB31 (RI:SI D31)
Double command 1-pole and 1½-pole
CA00, CA01
CA02, CA03
:
CA30, CA31
Command CA00/CA01 (RI:DI D00/D01)
Command CA02/CA03 (RI:DI D02/D03)
:
Command CA30/CA31 (RI:DI D30/D31)
CB00, CB01
CB02, CB03
:
CB30, CB31
Command CB00/CB01 (RI:DI D32/D33)
Command CB02/CB03 (RI:DI D34/D35)
:
Command CB30/CB31 (RI:DI D62/D63)
Double command 2-pole
CA00 / CB00, CA01 / CB01
CA02 / CB02, CA03 / CB03
:
CA30 / CB30, CA31 / CB31
Command CA00..CB01 (RI:DI D00/D01)
Command CA02..CB03 (RI:DI D02/D03)
:
Command CA30..CB31 (RI:DI D30/D31)
