System Components
SICAM RTUs, SICAM AK 3 User Manual 121
DC2-028-2.03, Edition 07.2016
2.5.3.4 External Circuitry
1-pole output, load on the plus pole
DO-2201
EXT+
U
EXT-
U
OUT D00+
OUT D00-
OUT D39+
OUT D39-
