Siemens SICAM RTU User Manual

Automation Units and Automation Networks
SICAM RTUs, SICAM AK 3 User Manual 241
DC2-028-2.03, Edition 07.2016
• Each bus interface module CM-0842 has to be supplied separately.
(18 VDC ... 78 VDC)
• Settings A on the Configuration switch CM-0842
1 F1/F2 ON 16 MBit
2 LINE2 OFF PE(A)
3 AS2 OFF 0
4 AS1 OFF 0
5 AS0 OFF 0
6 RED OFF CM-0842
7 LAD OFF inactive
8 LINE1 OFF PE
• Settings B on the Configuration switch CM-0842
1 F1/F2 ON 16 MBit
2 LINE2 ON BSE(E)
3 AS2 OFF 0
4 AS1 OFF 0
5 AS0 OFF 0
6 RED OFF CM-0842
7 LAD OFF inactive
8 LINE1 OFF PE
Necessary modules and cables
Designation Item-Number/MLFB
SICAM AK 3
Basic unit
CP-2016
Master control element CP-2016/CPCX26
BC2-016 / 6MF10130CA160AA0
CP-2019
Processing and communication element CP-
2019/PCCX26
BC2-019 / 6MF10132CA100AA0
Cable • Patch cable CAT5 (4x2) AWG26/7 T41-255 (1m) / 6MF13040BC550AA0
T41-251 (2m) / 6MF13040BC510AA0
T41-252 (3m) / 6MF13040BC520AA0
Bus Interface Mod-
ule
CM-0842 Ax 1703-bus interface 4x FO GA0-842 / 6MF11110AJ420AA0
Cable ‚ FO-INDOORCABLE-200-DUP-BREAK-ROUND
FO-CONNECTOR-ODLP-200 (2 pcs. per connection)
TF7-035TF7-015
FO-OUTDOORCABLE-200-2FIB-ARM
FO-CONNECTOR-ODLP-200 (2 pcs. per connection)
FO-PIPE SPLITTER 2Y-LR1 (2 pcs. per connection)
(only for outdoorcableTF7-036)
TF7-036TF7-015TF7-066
Peripheral elements
SICAM TM
PE-6411 peripheral coupling Ax-bus 1x optical GC6-411 / 6MF11130GE110AA0
