Siemens SICAM RTU User Manual

Service
SICAM RTUs, SICAM AK 3 User Manual 215
DC2-028-2.03, Edition 07.2016
Error (startup canceled) RY ER W BBD INT ACT EXT CPY HLT Note
Module defect
™ ˜ ™ ™ ™ ™ ™ ™ ˜
Exchange system element
PROM error (code)
™ ˜ ™ ™ ™ ™ ™ ™ ™
Exchange system element
RAM error (data)
™ ˜ ™ ™ ™ ™ ™ ™ ™
Exchange system element
Parameter files incomplete
*)
™ ˜ ™ ™ ˜ ™ ™ ™
§
SICAM TOOLBOX II diagnostic (initialize automa-
tion unit)
Checksum error of the parameters
™ ˜ ™ ™ ˜ ™ ™ ™
§
SICAM TOOLBOX II diagnostic (initialize automa-
tion unit)
Parameter error
™ ˜ ™ ™ ˜ ™ ™ ™
§
SICAM TOOLBOX II diagnosis
*)
applies for the main processor (M-CPU) on the master control element
Error (startup continued) RY ER W BBD INT ACT EXT CPY HLT Note
No flash card present
1)
˜ ˜
x x
˜
x x
™ ™
SICAM TOOLBOX II diagnosis (install flash card,
initialize automation unit)
Checksum error on the flash card
˜ ˜
x x
˜
x x
™ ™
SICAM TOOLBOX II diagnosis (initialize automa-
tion unit or load firmware, acc. to diagnosis )
Firmware code incomplete
1)
˜ ˜
x x
˜
x x
™ ™
SICAM TOOLBOX II diagnosis (load firmware
automation unit)
Configuration error
˜ ˜
x
˜
x x x
™ ™
SICAM TOOLBOX II diagnosis
Too little memory on the protocol
element or peripheral element
˜ ˜
x
˜
x x x
™ ™
SICAM TOOLBOX II diagnosis
Parameter error
˜ ˜
˜
2)
x
˜
2)
x x
™ ™
SICAM TOOLBOX II diagnosis
1)
applies for the main processor (M-CPU) on the master control element
2)
depending on type of error
