Fieldbus parameters
Table 5-32 Fieldbus parameters
Parameter ID Adjustment range Factory setting Description
Communication channel
p2020 0 ≙ 9600
1 ≙ 19200
2 ≙ 38400
3 ≙ 57600
4 ≙ 115200
5 ≙ 187500
6 ≙ 250000
7 ≙ 300000
8 ≙ 375000
9 ≙ 500000
10 ≙ 750000
4 Baud rate
p2021 0 … 31 0 Slave address
p2022 0 to 16 words 7 Number of PZDs
p2023 0 ≙ no PKW proportion
3 ≙ (3 words)
4 ≙ (4 words)
4 Number of PKWs
Statistical data
r2029 0 ≙ rejected telegrams
1 ≙ character frame
2 ≙ start character
3 ≙ block check character
4 ≙ telegram length
5 ≙ remaining execution time
6 ≙ telegram type
7 ≙ bu󹪜er over󹪞ow
— Error statistics
Monitoring
p2040 0 to 65535 ms
0 ≙ monitoring deactivated
1000 ms Monitoring time for master monitoring
Cyclic process values
p4700 0 … 10 0 As of V1.09: Value selection for cyclic transmission
of process value TZW3 (Page 327)
p4701 0 … 10 1 As of V1.09: Value selection for cyclic transmission
of process value TZW4 (Page 327)
p4702 0 … 10 2 As of V1.09: Value selection for cyclic transmission
of process value TZW5 (Page 327)
Controllers
5.9 Operation and con󹪝guration of the control unit
ATD4xxW for industrial applications
System Manual, 06/2022, A5E51901827B AA 191
