Parameter
ID
Name Description
Position block (as of V1.12)
p20061 DCMD_POS_Q69 Output is active as long as the door position is within the parameterized range.
FBLOCK-REF parameters
The inputs of the various F blocks can be connected or linked to any "Q" outputs (signal sources)
via the following FBLOCK-REF parameters. To this end, the number of the Q element must be
entered directly in the REF parameter (Q{0 to 38}).
Table 5-38 FBLOCK-REF parameters
Parameter ID Name Description
AND
p20100 REF_AND0_IN1 Input 1 logical AND gate 0
p20101 REF_AND0_IN2 Input 2 logical AND gate 0
p20102 REF_AND0_IN3 Input 3 logical AND gate 0
p20103 REF_AND0_IN4 Input 4 logical AND gate 0
p20104 REF_AND1_IN1 Input 1 logical AND gate 1
p20105 REF_AND1_IN2 Input 2 logical AND gate 1
(As of V1.10)
p20123 REF_AND2_IN1 Input 1 logical AND gate 2
p20124 REF_AND2_IN2 Input 2 logical AND gate 2
p20125 REF_AND2_IN3 Input 3 logical AND gate 2
p20126 REF_AND2_IN4 Input 4 logical AND gate 2
OR
p20106 REF_OR0_IN1 Input 1 logical OR gate 0
p20107 REF_OR0_IN2 Input 2 logical OR gate 0
p20108 REF_OR0_IN3 Input 3 logical OR gate 0
p20109 REF_OR1_IN1 Input 1 logical OR gate 1
p20110 REF_OR1_IN2 Input 2 logical OR gate 1
p20111 REF_OR1_IN3 Input 3 logical OR gate 1
NOT
p20112 REF_NOT0_IN1 Input logical NOT gate 1 (negation)
p20113 REF_NOT1_IN1 Input logical NOT gate 2 (negation)
XOR
p20114 REF_XOR0_IN1 Input 1 logical exclusive OR (XOR)
p20115 REF_XOR0_IN2 Input 2 logical exclusive OR (XOR)
FRQ
p20116 REF_FRQ0_IN1 Input frequency detection
p20117 REF_FRQ1_IN1 Input frequency detection
DELAY
p20118 REF_OnDELAY_IN1 ON delay
Special
Controllers
5.9 Operation and con󹪝guration of the control unit
ATD4xxW for industrial applications
System Manual, 06/2022, A5E51901827B AA 201
