Parameterizing the Mobile Panel
5.7 Configuring operation
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
101
4. Touch the center of the calibration cross until it is shown at the next position. The
calibration cross appears at four other positions.
Once you have touched the calibration cross at all positions, the following dialog appears:
5. Touch the touch screen within the indicated time.
The calibration will be saved. The "Touch" tab is displayed once again in the "OP
Properties" dialog. If you do not touch the touch screen within the time shown, your
original setting will be retained.
6. Close the "OP Properties" dialog with "OK".
The touch screen of the HMI device is calibrated.
5.7.6
Restarting the HMI device
You need to perform a restart in the following situations:
● You have enabled or disabled the PROFINET IO direct keys, see section
"Enabling NTP (Page 127)".
● You have changed the time zone and activated daylight saving time, see section
"Setting the date and time (Page 104)".
● You have changed the settings for the screensaver, see section
"Setting the screen saver (Page 107)".
● You have changed the retentivity behavior of the alarm buffer, see section
"Activate/deactivate retentivity of the alarm buffer on the HMI device (Page 113)".
NOTICE
Data loss
All volatile data is lost with a restart.
Make sure that no project is running on the HMI device and no data is being written to the
flash memory.

Siemens SIMATIC HMI series Specifications

General

Series	SIMATIC HMI
Category	Control Panel
Display Type	TFT LCD
Touch Screen	Yes (resistive or capacitive, depending on model)
Processor	Varies by model (e.g., ARM-based processors)
Storage	Varies by model (e.g., Flash memory, microSD card slot)
Communication Interfaces	Ethernet, USB
Protection Class	IP65 (front panel), depending on model
Operating Temperature	0 to 50°C, -20 to 60°C
Power Supply	24 V DC
Memory	128 MB, 256 MB
