Siemens SIMATIC HMI series User Manual

Technical specifications
11.12 Communication with controllers
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
253
11.12
Communication with controllers
Number of connections
The table below shows the maximum number of controller connections for a Mobile Panel
2nd Generation.
Connection Type
Number of connections, via connection box
With bus connection
8
With "SIMATIC HMI HTTP protocol" 8
Compatible controllers
The table below shows the controllers that you can connect to the HMI device via the
connection boxes.
PLC
Compatible with Mobile Panels 2nd Generation
SIMATIC S7-1500, SIMATIC S7-1500F
Yes
SIMATIC S7-400, SIMATIC S7-400F Yes
SIMATIC S7-300, SIMATIC S7-300F
Yes
SIMATIC S7-1200, SIMATIC S7-1200F Yes
SIMATIC S7-200
Yes
LOGO
Yes
SIMATIC HTTP Protocol
Yes
OPC-XML-DA-Server
No
OPC UA
Yes
Allen-Bradley EtherNet/IP
Yes
Allen-Bradley DF1
No
Mitsubishi MC TCP/IP
Yes
Mitsubishi FX
No
Modicon Modbus TCP/IP
Yes
Modicon Modbus RTU
No
Omron Hostlink
No
NOTICE
In PROFIsafe-based F-system only use S7-12xx CPUs with firmware version ≥ 4.1.
When using a S7-12xx CPU with firmware version <4.1 in a PROFIsafe-based F-system,
faults can occur in the PROFIsafe communication.
If you are using an S7-12xx CPU in a PROFIsafe-based F-system, this CPU must have a
firmware version ≥4.1.
