Siemens SIMATIC HMI series User Manual

Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
43
Installing system components
3
3.1
Checking the delivery
Check the scope of delivery for visible signs of shipping damage and make sure that it is
complete, see section "Scope of delivery (Page 20)".
Note
Do not install parts damaged during shipment. In the case of damaged parts, contact your
Siemens representative. See section "
Service and support (Page 268)".
3.2
Mounting the connection box compact
3.2.1
Mounting position, mounting cutout and clearance
Mounting position
The connection box is designed for installation in the following types of fixed enclosure:
● Mounting cabinets
● Control cabinets
● Control panels
● Consoles
The connection box compact can be installed in any mounting position.
Mounting cutout
The degree of protection is guaranteed if the following conditions are met:
Material thickness at the mounting
cutout
2 to 6 mm
Deviation from plane at the mounting
cutout
≤ 0.5 mm
This condition also applies for the installed connection box.
Surface roughness in the area of the
mounting seal
≤ 120 µm (R
z
120)

Siemens SIMATIC HMI series Specifications

General

Series	SIMATIC HMI
Category	Control Panel
Display Type	TFT LCD
Touch Screen	Yes (resistive or capacitive, depending on model)
Processor	Varies by model (e.g., ARM-based processors)
Storage	Varies by model (e.g., Flash memory, microSD card slot)
Communication Interfaces	Ethernet, USB
Protection Class	IP65 (front panel), depending on model
Operating Temperature	0 to 50°C, -20 to 60°C
Power Supply	24 V DC
Memory	128 MB, 256 MB
