Technical specifications
11.6 Climatic ambient conditions
Mobile Panels 2nd Generation
224 Operating Instructions, 09/2018, A5E33876626-AC
Climatic ambient conditions
11.6.1
The following information applies to a device that is stored in its original packaging for longer
than two weeks.
The device meets the requirements according to IEC 60721-3-1 Class 1K21.
Transport and short-term storage
The following information applies to an HMI device and connection box transported and
stored in its original packaging.
The device was tested based on IEC 60721-3-2 Class 2K11 with the following amendments
and limitations:
Atmospheric pressure 1140 ... 660 hPa, corresponds to an elevation of -1000 to 3500 m
Pollutant concentration SO
2
: < 0.5 ppm; relative humidity < 60%, no condensation
H
2
S: < 0.1 ppm; relative humidity < 60%, no condensation
Note
If dewing has developed, wait until the device has dried completely before switching it on.
Do not expose it to direct heat radiation from a heating device.
The following information applies to the HMI device and to the connection box. The devices
are designed for operation in a location protected from the effects of the weather. The
devices were tested based on IEC 60721-3-3 Class 3K3 with the following amendments and
limitations:
Temperature, connection boxes
1140 ... 795 hPa, corresponds to an elevation of -1000 to 2000 m
10 ... 90%, no condensation
Pollutant concentration SO
2
: < 0.5 ppm; relative humidity < 60%, no condensation *
2
S: < 0.1 ppm; relative humidity < 60%, no condensation *
* Mobile Panel, connection box standa
rd and connection box advanced:
No condensation inside the housing
Connection box compact: None condensation on the back
