Siemens SIMATIC HMI series User Manual

Technical specifications
11.8 Technical specifications
Mobile Panels 2nd Generation
Operating Instructions, 09/2018, A5E33876626-AC
233
11.8
Technical specifications
11.8.1
Mobile Panel
Mechanics
KTP400F
Mobile
KTP700
Mobile
KTP700F
Mobile
KTP900
Mobile
KTP900F
Mobile
Weight without packaging Approx.
900 g
Approx.
1200 g
Approx.
1300 g
Approx.
1500 g
Approx.
1600 g
Fall height
1.2 m
Weight of the KTP Mobile
wall-mounting bracket without
packaging
Approx. 1000 g
Display
KTP400F Mobile
KTP700 Mobile
KTP700F Mobile
KTP900 Mobile
KTP900F Mobile
Type
LCD TFT
Active display area
95 × 53 mm
154.1 × 85.9 mm
195 mm x 117 mm
Resolution
480 × 272 pixels
800 × 480 pixels, widescreen
Color depth
16-bit, 24-bit
Brightness control
By software
Backlighting
Half Brightness Life Time (MTBF
1
)
LED
≥ 50,000 h
Pixel error class in accordance with
EN ISO 9241-307
II
1
Operating hours after which the maximum brightness is reduced by half compared to the original
value. MTBF is increased by using the integrated dimming function, for example, time-controlled
via screen saver or centrally via PROFIenergy.
Input device
KTP400F Mobile
KTP700 Mobile
KTP700F Mobile
KTP900 Mobile
KTP900F Mobile
Type
Touch screen, analog resistive
Function keys
4
8
10
Labeling strips
No

Siemens SIMATIC HMI series Specifications

General

Series	SIMATIC HMI
Category	Control Panel
Display Type	TFT LCD
Touch Screen	Yes (resistive or capacitive, depending on model)
Processor	Varies by model (e.g., ARM-based processors)
Storage	Varies by model (e.g., Flash memory, microSD card slot)
Communication Interfaces	Ethernet, USB
Protection Class	IP65 (front panel), depending on model
Operating Temperature	0 to 50°C, -20 to 60°C
Power Supply	24 V DC
Memory	128 MB, 256 MB
